You can specify the color assigned to a particular pen, so that you can match the original colors of the graphic. When imported into a Corel program, each pen number is assigned a specific color. Instead, the various objects in a PLT file have certain pen numbers associated with them. The PLT file format does not contain color information. A curve resolution of 0.004 inch is recommended. A setting of 0.0001 results in the highest resolution, but it also greatly increases file size. The value can be very precise up to eight decimal places are accepted. The curve resolution factor can be set to a value between 0.0001 and 1.0 inch. You can import images larger than the Corel program’s maximum page size by enabling the Scale option in the HPGL options dialog box, which lets you resize the imported image. In the HPGL export dialog box, adjust any of the settings.Ĭorel programs support versions 1 and 2 of PLT file formats although some features of version 2 are not supported. Type a filename in the File name list box. Locate the folder where you want to store the file.Ĭhoose PLT - HPGL Plotter File from the Save as type list box. In the HPGL options dialog box, adjust any of the settings. Locate the folder in which the file is stored.Ĭhoose PLT - HPGL Plotter File (*.plt *.hgl) from the list box next to the File name box.
This format uses a scaling factor of 1,016 plotter units to 1 inch.
Other Corel applications can interpret a SUBSET of the HPGL and HPGL/2 command set. It is used in programs such as AutoCAD for printing drawings on plotters. The HPGL Plotter File (PLT) format, developed by Hewlett-Packard, is vector-based.
